Mining Equipment from 1930's










Mining Equipment from 1930's

S-D Automatic Installations




Harvey Coal Corporations
S-D Automatic - Door Trailers

Tandem S-D Automatic-Door Trailers-- Over the Bin.
sanford114_2.jpg (46734 bytes) Tandem S-D Automatic-Door Trailers-- In action.
sanford115_1.jpg (18415 bytes) A battery of S-D Automatic Bottom-Dump Trailers.
sanford115_2.jpg (57143 bytes) S-D Automatic-Door Trailers-- In action.
sanford116_4.jpg (59223 bytes) Showing a big stripping operating using S-D Automatic Trailers.
Special Types of Cars
sanford98_1.jpg (47187 bytes) "Man-Car" For Incline.   Specification: Man-Car. Capacity 60 men.  track gauge 72 inches.   Length overall 22 ft.  Height overall 10 ft.  width overall 11 ft.   Wheels 20 inches.  Axles 4 inches.  Wt. 9900 lbs.
S-D "Automatics" Are In Wide Use
sanford43_1.jpg (48190 bytes) S-D "Automatics" in Big West Virginia Mine.
sanford43_3.jpg (41291 bytes) S-D "Whopper Automatics" in Strip Mining.
sanford43_4.jpg (51822 bytes) S-D "Automatics" in Strip Mine in Kentucky
